1KW Key Shaft 19.05 Dynamo High Output Alternator 3600rpm 60Hz / 3000rpm 50Hz Speed

Name: 1KW Key Shaft 1905 Dynamo High Output Alternator 3600rpm 60Hz 3000rpm 50Hz Speed
Brand: GENFOR
Price: 1 USD

China 1KW Key Shaft 19.05 Dynamo High Output Alternator 3600rpm 60Hz / 3000rpm 50Hz Speed wholesale

Brand Name : GENFOR

Model Number : GFA160-1.0 B3

Certification : CE

Place of Origin : China

MOQ : Sample accept

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 1000pcs per month

Delivery Time : 20-25days

Packaging Details : Carton/box

Speed : 3600rpm 60Hz / 3000rpm 50Hz

Voltage : As request

Copper Wire : 100% Copper

Brush : Yes

Voltage Regulator : AVR

Max.Power : 1.1KW

Rated Power : 1.0KW

Shaft ouput : As Request

Contact Now

1KW Key Shaft 19.05 Dynamo High Output Alternator Electrical Power Pully Belt Type

Model: GFA160-1.0 B3

Max. Power Output: 1.1KW

Rated Power Output: 1.0KW

Back with Power output,control box,with down-lead type for Choice

Delivery.

Generally, it will take 15 to 20 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

We will recommend the most suitable shipping method for you.

Package.

We have different original packages for selling in different counties.
we also can custom the packages as you want..

We have strict packaging to ensure that the goods are not damaged and safely reach your hands.

1KW Key Shaft 19.05 Dynamo High Output Alternator 3600rpm 60Hz / 3000rpm 50Hz Speed

TECHNICAL DATE
型号Type		额定功率Rated Power (KVA)	最大功率Max Power (KVA)	机器总尺寸及安装尺寸 Overall&Mounting Dimensions(mm)
				A	B	D	K	ΦF
GFA160-1.0 B3	50Hz-3000r.p.m	1.0	1.1	290	60	20/22	16.5/18	6/8
	60Hz-3000r.p.m	1.2	1.3
GFA160-1.5 B3	50Hz-3000r.p.m	1.5	1.7	300	70
	60Hz-3000r.p.m	1.8	2.0
GFA160-2.0 B3	50Hz-3000r.p.m	2.0	2.2	315	85
	60Hz-3000r.p.m	2.2	2.5
GFA160-2.5 B3	50Hz-3000r.p.m	2.5	2.8	340	110
	60Hz-3000r.p.m	2.8	3.0
GFA160-3.0 B3	50Hz-3000r.p.m	3.0	3.2	350	120
	60Hz-3000r.p.m	3.2	3.3
Note:The data for your information only ,and changes based on practicality

Insulation Class:CL.F(△T≦130K)

Power Factor:CosΦ=1(Single-phase);CosΦ=0.8(Three-phase)

Rated Voltage:110,115,120,220,230,240,110/220,115/230,120/240.

DC Output:12V/8.3A(Optional)

Excitation Type:Brush&Brushless
